Exulted 3kVA 24V Hybrid Inverter (In-Built MPPT Controller)

Exulted 3kVA 24V Hybrid Inverter (In-Built MPPT Controller)

Product Details

The Exulted 3kVA 24V Hybrid Inverter is engineered to deliver dependable power for homes, small offices, and light commercial setups. Its pure sine wave output provides clean and stable electricity comparable to grid power, making it safe for sensitive electronics such as televisions, computers, decoders, and sound systems while also supporting common household appliances.

The inverter features an integrated MPPT (Maximum Power Point Tracking) solar charge controller, which maximizes solar energy production by continuously tracking the optimal voltage and current from solar panels. This advanced technology improves charging efficiency, increases solar energy utilization, and reduces overall energy losses.

Designed for hybrid energy operation, the inverter can work with solar panels, battery storage, utility grid power, or generator supply, allowing users to enjoy uninterrupted electricity even during power outages. The system intelligently prioritizes solar energy when available, helping reduce electricity costs and improve energy independence.

The inverter runs on a 24V battery bank, typically configured with two 12V batteries connected in series. However, four batteries are recommended to improve energy storage capacity, enhance system stability, and provide longer backup duration under load.

Built-in protection systems safeguard the inverter and connected equipment from overload, short circuits, overheating, over-voltage, and low battery conditions, ensuring reliable operation and extended system lifespan.

With an estimated practical load capacity of up to 3kVA, this inverter can comfortably power essential household appliances and electronic devices.

Estimated Load Capacity (Approx. 3kVA)

The system can conveniently power the following appliances simultaneously:

1 Refrigerator or 1 Freezer
3 Ceiling Fans
20 Lighting Points (5W LED)
1 DSTV Decoder
2 LED Televisions
1 Music System
1 Personal Computer or Equivalent Devices

Battery Requirement

System Voltage: 24V
Minimum Configuration: 2 × 12V Batteries
Preferred Configuration: 4 × 12V Deep Cycle Batteries for better efficiency and longer backup duration

Warranty

2 Years Manufacturer’s Warranty

Technical Specifications

Brand	Exulted
Model	Hybrid Solar Inverter
Rated Power Capacity	3kVA / 3000VA
Estimated Practical Load Capacity	Up to ~3kVA
System Voltage	24V DC
Output Waveform	Pure Sine Wave
Output Voltage	220V / 230V AC
Output Frequency	50Hz ±0.5Hz
Conversion Efficiency	Up to 90–93%
Solar Charge Controller	Built-in MPPT
Maximum PV Input Power	Up to 3000W
PV Input Voltage Range	Approximately 60V – 145V DC
Maximum Solar Charging Current	Up to 80A
Battery Bank Voltage	24V
Minimum Battery Requirement	2 × 12V Batteries
Recommended Battery Configuration	4 × 12V Batteries
Compatible Battery Types	Tubular Batteries, AGM Batteries, Gel Batteries, Lithium Batteries
Protection Features	Overload Protection, Short Circuit Protection, Over-temperature Protection, Low Battery Protection, Over-voltage / Under-voltage Protection, Automatic Restart Function
User Interface	LCD Display Screen, LED Status Indicators, Real-time Monitoring (Battery Level, Load Status, Charging Status)
Cooling System	Intelligent Temperature-Controlled Cooling Fan
Operating Temperature	−10°C to 50°C
Relative Humidity	5% – 95% (non-condensing)
